ST104A卧式离子风机
ST104A卧式离子风机
|
ST104A卧式离子风机,在ST105A卧式风机设计基础上而成，使其更小巧、轻便。可根据需求安装实时监控报警系统。可调节离子风量，内置高压发生器。 |
||||
|
技术参数： |
||||
|
工作电压 |
110V/60HZ 或 220V/50HZ |
|||
|
消耗电流 |
3.0A 或 1.5A |
|||
|
操作温度 |
-10～50℃ |
|||
|
外型尺寸 |
400mm(长)×220mm(宽)×190mm(高) |
|||
|
重量 |
5.8Kg |
|||
|
风量 |
70～120CFM |
|||
|
离子平衡 |
0V±10V |
|||
|
气流面积 |
60cm×120cm |
|||
|
测试结果： |
||||
|
测试条件 |
测试电压：1KV-100V 操作电压：110/220V 环境温度：22℃ 测试湿度：75%RH |
|||
|
距离 |
300mm |
600mm |
900mm |
1200mm |
|
左300mm |
1.3s |
2.5s |
3.9s |
6.6s |
|
中心 |
1.1s |
2.2s |
3.6s |
6.5s |
|
右300mm |
1.2s |
2.3s |
3.8 |
6.3s |
ST104A HORIZONTAL IONIZING AIR BLOWER
|
ST104A HORIZONTAL IONIZING AIR BLOWER, On the base of design of ST105A horizontal ioni-zing air blower, it is smaller and more portable.Can install ionizing equilibrium measurement realtime supervising and alarming system as request.The ionizing air volume can be adjusted, including high voltage generator. |
||||
|
Specification： |
||||
|
Operating Voltage |
110V/60HZ OR 220V/50HZ |
|||
|
Current Consumption |
3.0A OR 1.5A |
|||
|
Operating Temperature |
-10～50℃ |
|||
|
Size |
400mm(L)×220mm(W)×190mm(H) |
|||
|
Weight |
5.8Kg |
|||
|
Air Volume |
70～120CFM |
|||
|
Ion Balance |
0V±10V |
|||
|
Air Coverage |
60cm×120cm |
|||
|
Decay tdst Results： |
||||
|
Testing Conditions |
Test voltage：1KV-100V Operating Voltage：110/220V Temperature：22℃ Test Humidity：75%RH |
|||
|
Distance |
300mm |
600mm |
900mm |
1200mm |
|
Left300mm |
1.3s |
2.5s |
3.9s |
6.6s |
|
Center |
1.1s |
2.2s |
3.6s |
6.5s |
|
Right300mm |
1.2s |
2.3s |
3.8 |
6.3s |
